Sideview | Mini | Digital Tape

sideview digital led tape

    1. Input Voltage DC5V, Single signal (data) control.
    2. SK6812/WS2812B IC embedded in SMD4020 sideview RGB LED.
    3. 60leds/m,144leds/m Available,each led is programmable.
    4. 16.6mm/0.65”,6.9mm/0.27" intervals cutting point
    5. 5mm PCB for 60leds,8mm PCB for 144leds,White/Black PCB available.
    6. Both ends wired with 150mm/5.9" 20Awg wire and JST 3Pin male/female connector
    7. 3M adhensive tape stick on the back of non-waterproof version.
    8. Controller System:SD controller , DMX controller , Artnet.
    9. details please download datasheet.

    Product Model
    M/N Size/mm IP Rate Voltage Led type IC type Leds/m Pixel/m Luminous/m Angle Watt/m
    GE60RGB6812ASV 1000*5*2.5   IP21 DC5V SMD4020         Sideview SK6812
    Built-in
    60 60 R:100lm
    G:200lm B:80lm
     Mix W:320lm
    120 9w
    GE144RGB6812ASV 1000*8*2.5   IP21 DC5V SMD4020         Sideview SK6812
    Built-in
    144 144 R:240lm
    G:480lm B:196lm
     Mix W:750lm
    120 21w
    GE60RGB2812BASV 1000*5*2.5   IP21 DC5V SMD4020         Sideview WS2812B
    Built-in
    60 60 R:100lm
    G:200lm B:80lm
     Mix W:320lm
    120 9w
    GE144RGB2812BASV 1000*8*2.5   IP21 DC5V SMD4020         Sideview WS2812B
    Built-in
    144 144 R:240lm
    G:480lm B:196lm
     Mix W:750lm
    120 21w
    Welcome your inquiry, we will reply you within 24 hours.

    *

    *

    *

    *
