| Waterproof DC12V/24V Series | ||||||
| M/N | Input Voltage | Output Voltage | Ouput current at DC12/24V |
Wattage | size | N.W |
| WS-60 | AC90-135V AC175-265V |
DC12V/24V | 5.0A/2.5A | 60W | 190*48*34mm | 650g |
| WS-100 | AC90-135V AC175-265V |
DC12V/24V | 8.4A/4.2A | 100W | 180*69*43mm | 900g |
| WS-120 | AC90-135V AC175-265V |
DC12V/24V | 10A/5A | 120W | 222*69*43mm | 1250g |
| WS-150 | AC90-135V AC175-265V |
DC12V/24V | 12.5A/6.25A | 150W | 222*69*43mm | 1350g |
| WS-200 | AC90-135V AC175-265V |
DC12V/24V | 16.6A/8.3A | 200W | 245*70*48mm | 1460g |
| WS-240 | AC90-135V AC175-265V |
DC12V/24V | 20A/10A | 240W | 235*120*58mm | 2500g |
| WS-300 | AC90-135V AC175-265V |
DC12V/24V | 25A/12.5A | 300W | 235*127*58mm | 2650g |
| Remark: maximum load 80% Rated power, never operate at full load | ||||||
| Waterproof DC5V Series | ||||||
| M/N | Input Voltage | Output Voltage | Ouput current | Wattage | size | N.W |
| WS-60-5 | AC90-135V AC175-265V |
DC5V | 12A | 60W | 180*69*43mm | 900g |
| WS-100-5 | AC90-135V AC175-265V |
DC5V | 20A | 100W | 222*69*43mm | 1350g |
| WS-150-5 | AC90-135V AC175-265V |
DC5V | 30A | 150W | 245*70*48mm | 1460g |
| WS-200-5 | AC90-135V AC175-265V |
DC5V | 40A | 200W | 235*127*58mm | 2500g |
| Remark: maximum load 80% Rated power, never operate at full load | ||||||
